EM30
TRACKING WEBCAM

Specifications

Camera

• Sensor:1/2.5'', CMOS, Effective Pixel

• Scanning Mode:Progressive

• Lens Mount:M12

• Lens 1:Focus

• Lens 2:Focus

• Minimal Illumination:0.5 Lux @ (F1.8, AGC ON)

• Shutter:1/30s ~ 1/10000s

• White Balance:Auto, Indoor, Outdoor, One Push, Manual

• Camera bracket:bracket with damper

• Digital Noise Reduction :2D,3D digital noise reduction

• Backlight Compensation:Support

• Horizontal/Portrait screen mode:Support

• Low Light:Support

• AI mode: Autoframing/Speaker Tracking/Body Tracking

Input/Output Interface

• USB Interface:1xUSB 3.0

USB Features

• Operate System:Windows® 7 (1080p and under only), Windows 8.1, Windows 10 or higher macOS™ 10.10 or higher Google™ Chromebook™ Version 76.0.3809.136 or higher versions Linux(support for UVC needed);Android

• Hardware Requirements:2.4 GHz Intel® Core 2 Duo processor or higher 2 GB RAM or more USB 2.0 port (USB 3.0 required for 4K)

• Color System / Compression: MJPEG/YUY2/H.264

• Video Format: 4k@30fps/25fps, 1080p@30fps/25fps, 720p@30fps/25fps, 960x540p@30fps/25fps,etc

• USB Video Communication Protocol:UVC 1.1

• UVC PTZ: Support(EPTZ)

General specification

• Input Voltage:5V (USB power supply)

• Current Consumption:800mA（max）

• Operating Temperature:-10°C ~ 40°C (14°F ~ 104°F)

• Storage Temperature:-40°C ~ 60°C (-40°F ~ 140°F)

• Power Consumption:4W（max）

• Size:194mm x 34mm x 42mm (without bracket)

• Net Weight:0.5KG

• MTBF:30000h
